Features

• Simultaneous recording from GC and EAG inputs at 100 Sa/s
• Data oversampled at 1.9 KHz, 16 bits
• Very high cross-talk immunity between EAG and GC inputs
• Digital trigger input
• Input signal range is -1 to +1 VDC
• Signal dynamic range is 50 mV
• Low noise - approximately 2 µV peak to peak
• Single pole digital high-pass filter continuously selectable
• Selectable Low-pass filtering types including Butterworth and Bessel filters. Filter order and cutoff frequency may be specified
• Separate low-pass digital filtering may be applied to GC input
• Selectable 7 Hz or 50 Hz input lowpass filter
• Data exportable to text format
